Description
secure support of engine or gearbox during assembly
is required for e.g. disassembly of the engine mount, timing belt and replacement of clutch
sturdy square tube construction
feets and support plate are height adjustable and lockable
rotatable retaining hooks, adjustable in height by hand wheel
slidable and fixable crosspiece and retaining hook
support plate with non-slip rubber pad
especially suitable for large fender angle, where a mounting of engine bridge is very difficult
suitable for many common vehicles
length of the longitudinal beam: 690 up to 1050 mm
max. retaining hook distance: 500 mm
crossbeam supporting foot distance: 450 mm
Technical data
Gross weight 11700 g
